Anasorb Sorbent Tubes

The Anasorb® name is used for SKC proprietary sorbents of all types.

Anasorb Sorbent Tubes
Anasorb Sorbent Tubes

To select a tube for a specific compound refer to the SKC Sampling Guides or use our SKC online Hazard Database

Anasorb® 747

Anasorb® 747 is a synthetic carbon with low ash content which studies showed as a candidate material for sampling polar organic compounds that cannot be sampled using coconut charcoal, such as ketones. Anasorb 747® has properties similar to the best petroleum charcoals and can be used for a very wide range of polar and non-polar organic vapours. When combined with a solvent appropriate to mixtures such as dimethylformamide, successful sampling is possible for a majority of organic vapours.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb 747 6 x 70  2 140/70 GS A   FWW 20 226-81A
Anasorb 747 8 x 110  2 400/200 GS B   FWW 50 226-83
Anasorb 747 10 x 110  2 800/200 GS C   FWW 20 226-84
Anasorb 747 (hydrobromic acid) 6 x 70  2 100/50 GS A   WWW 20 226-178
Anasorb 747 (potassium hydroxide) 6 x 70  2 100/50 GS A   FWW 50 226-80
Anasorb 747 (sulphuric acid) 8 x 110  2 500/250 GS B   WWW 50 226-29
Anasorb 747
Anasorb 747
2 tubes total
8 x 110
8 x 110
 1
 1
400
200
GS
GS
D   FW
FW
20 Sets 226-82

Table Notes:

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring

Anasorb® 727

Anasorb® 727 is a microporous polymer for sampling less volatile reactive and polar compounds. It is derived from cross-linked styrene and similar monomers, and its sorbent properties are similar to Chromosorb® 106. The surface area is large, very unreactive, and extremely hydrophobic.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb 727 8 x 110  2 300/150 GS B   WWW 20 226-75

Table Notes:

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring

Anasorb® 708

Anasorb® 708 is equivalent to Chromosorb® 108.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb 708 6 x 70  1 100 GS A   WW 50 226-30-08
Anasorb 708 6 x 70  2 75/37 GS A   WWW 50 226-49-108

Table Notes:

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring

Anasorb® C300

Anasorb® C300 sorbent is equivalent to Hydrar, Carulite.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb C300 8 x 110  1 500 GS B   WW 50 226-17-3A
Anasorb C300 6 x 70  1 200 GS A   WW 50 226-17-1A

Table Notes:

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring

Anasorb® CSC

Anasorb® CSC sorbent has a high surface area for sampling a broad range of primarily non-polar compounds.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb CSC, Coconut Charcoal 6 x 70  2 100/50 GS A   FFW 50 226-01
Anasorb CSC, Coconut Charcoal 10 x 160  2 1800/200 GS D   FWW 50 226-16-02
Anasorb CSC, Coconut Charcoal 10 x 110  2 800/200 GS C   FWW 50 226-16
Anasorb CSC, Coconut Charcoal 8 x 110  2 400/200 GS B   FWW 1000 226-09-BULK
Anasorb CSC, Coconut Charcoal 8 x 110  2 400/200 GS B   FWW 500 226-09-500
Anasorb CSC, Coconut Charcoal 8 x 110  2 400/200 GS B   FWW 50 226-09
Anasorb CSC, Coconut Charcoal 6 x 70  2 100/50 GS A   WWW 50 226-01GWS
Anasorb CSC, Coconut Charcoal 6 x 70  2 100/50 GS A   FFW 1000 226-01-BULK
Anasorb CSC, Coconut Charcoal 6 x 70  2 100/50 GS A   FFW 10 226-01A
Anasorb CSC, Coconut Charcoal 8 x 150  3 350/350/350 GS C   WWWW 50 226-09-02
Anasorb CSC, Coconut Charcoal (potassium hydroxide) 6 x 70  2 100/50 GS A   WRWW 50 226-67
Anasorb CSC, Coconut Charcoal
Anasorb CSC, Coconut Charcoal
2 tubes total
8 x 110

8 x 110
 1

 1
200

400
GS

GS
D   FW

FW
50 Sets 226-37
Anasorb CSC, Coconut Charcoal
Anasorb CSC, Coconut Charcoal
2 tubes total
8 x 110

8 x 110
 1

 1
200

400
GS

GS
D   WW

WW
50 Sets 226-25
Anasorb CSC, Coconut Shell Charcoal (t-butylcatechol) 6 x 70  2 100/50 GS A   WWW 50 226-73
XAD-2/XAD-2/Anasorb CSC 8 x 110  3 50/100/150 GS B   WWWW 50 226-192
Anasorb CSC, Coconut Charcoal (t-butylcatechol) 8 x 110  2 400/200 GS  B    WWW 20 226-196

Table Notes:

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring

Anasorb® GCB1/GCB2

Anasorb® GCB1 - Graphitised Carbon Black for sampling aliphatic and aromatic hydrocarbons and is equivalent to Carbotrap® B (20/40) and Carbopack B (60/80). This sorbent has proven to be valuable for sampling compounds of intermediate to high volatility.

Anasorb® GCB2 - Graphitised Carbon Black for sampling less volatile compounds. This sorbent has a low surface area and is equivalent to Carbotrap® C (20/40) and Carbopack C (60/80), and is useful in collecting semi-volatile organic compounds (SVOCs).

Note that thermally purged sorbent tubes are for immediate use in the field. Unpurged tubes are purged by a laboratory as needed.

Sorbent
(coating)
Size (mm)
ODxLength
Sections Sorbent
(mg)
Ends Tube
Cover
Separators Pack
Size
Part Number
Anasorb GCB1 (purged) 1/4 x 3-1/2 in  1 400 SS B   SWWS Each 226-356    §
Anasorb GCB1 (unpurged) 1/4 x 3-1/2 in  1 400 SS B   SWWS Each 226-356-UP    §
Anasorb GCB1/Carbosieve S-III (purged) 1/4 x 3-1/2 in  2 250/150 SS B   SWS Each 226-349    §
Anasorb GCB1/Carbosieve S-III (unpurged) 1/4 x 3-1/2 in  2 250/150 SS B   SWS Each 226-349-UP    §
Anasorb GCB1/Carbosieve S-III (purged) 1/4 x 3-1/2 in  2 175/80 GO B   WWW Each 226-346    §
Anasorb GCB1/Carbosieve S-III (unpurged) 1/4 x 3-1/2 in  2 175/80 GO B   WWW Each 226-346-UP    §
Anasorb GCB2/GCB1/Carbosieve S-III (purged) 1/4 x 3-1/2 in  3 120
/125
/105
GO B   WWWW Each 226-347    §
Anasorb GCB2/GCB1/Carbosieve S-III (unpurged) 1/4 x 3-1/2 in  3 120
/125
/105
GO B   WWWW Each 226-347-UP    §
Anasorb GCB2/GCB1/Carbosieve S-III (purged) 1/4 x 3-1/2 in  3 210
/140
/165
SS B   SWWWS Each 226-350    §
Anasorb GCB2/GCB1/Carbosieve S-III (unpurged) 1/4 x 3-1/2 in  3 210
/140
/165
SS B   SWWWS Each 226-350-UP    §
Tenax GR/Anasorb GCB1 (purged) 1/4 x 3-1/2 in  2 175/150 SS B   OSWSO Each 226-348    §
Tenax GR/Anasorb GCB1 (unpurged) 1/4 x 3-1/2 in  2 175/150 SS B   OSWSO Each 226-348-UP    §
Tenax GR/Anasorb GCB2 (purged) 1/4 x 3-1/2 in  2 125/120 GO B   WWW Each 226-345    §
Tenax GR/Anasorb GCB2 (unpurged) 1/4 x 3-1/2 in  2 125/120 GO B   WWW Each 226-345-UP    §

Table Notes:

‡  Tubes are chemically conditioned before shipping; use within 6 months or recondition. Restocking fee applies.
§  Each tube has a flow direction arrow and unique number.

Tube Ends:

GS:  Glass Sealed
GO: Glass Open
SS:  Stainless Steel Open

Protective Tube Covers:

A:  6 mm OD x 70 mm length
B:  8 mm OD x 110 mm length
C:  10 mm OD x 150 mm length
D:  10 mm OD x 220 mm length and shorter tubes
P:   Low-volume PUF Tube Holder - Do not use an adjustable low flow holder
V:  OVS Tube Holder - Do not use an adjustable low flow holder

Separators:

W:  Glass Wool
G:  Glass Fibre Filter
F:  Foam
N:  Nylon Ring
Q:  Quartz Filter
R:  Glass Spacer
S:  Screen
T:  PTFE Ring
O: Other

Trademarks:

Anasorb® — SKC Inc
Chromosorb ® — Manville Corp.
Porapak ® — Waters Associates, Inc.
Tenax ® — Buchem B.V.
XAD ® — Rohm & Haas
